- 1. ELECTRICAL SPECIFICATION
The accuracy specification is defined as ± ( percent of reading + digit ) At 23±5°C, ≦80 %RH.
3-1 ACmA (True RMS)
Range | Resolution | Accuracy |
50~60Hz | 50~500Hz |
6.000mA | 0.001mA | 1.0% + 8dgts | 2.0% + 8dgts |
60.00mA | 0.01mA | 1.0% + 5dgts | 2.0% + 5dgts |
600.0mA | 0.1mA |
Zero correction: Fractions smaller than approximately 0.006 mA are calibrated to zero.
Low Pass Filter
Range | Resolution | Accuracy |
6.000mA | 0.001mA | 2.0% + 8dgts |
60.00mA | 0.01mA | 2.0% + 5dgts |
600.0mA | 0.1mA |
3-2 ACA (True RMS)
Range | Resolution | Accuracy |
50~60Hz | 50~500Hz |
6.000A | 0.001A | 1.0% + 5dgts | 2.0% + 5dgts |
60.00A | 0.01A |
Low Pass Filter
Range | Resolution | Accuracy |
6.000A | 0.001A | 2.0% + 5dgts |
60.00A | 0.01A |
3-3 ACV (True RMS)
Range | Resolution | Accuracy |
50~500Hz |
60.00V | 0.01V | 1.0% ± 3dgts |
600.0V | 0.1V |
Input impedance: 2MΩ
3-4 DCV
Range | Resolution | Accuracy |
60.00V | 0.01V | 1.0% + 2dgts |
600.0V | 0.1V |
Input impedance: 2MΩ
3-5 Continuity
Range | Buzzer Function |
| Ohm < 45Ω |
3-6 Resistance (Ω)
Range | Resolution | Accuracy |
600.0Ω | 0.1Ω | 1.0% + 2dgts |
6.000KΩ | 0.001KΩ |
60.00KΩ | 0.01KΩ |
600.0KΩ | 0.1KΩ |
